Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm

    Buy cheap Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm from wholesalers

    Buy cheap Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm from wholesalers
    • Buy cheap Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm from wholesalers

    Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm

    Ask Lasest Price
    Brand Name : China Jinggong
    Model Number : HZZ5090TFZ
    Certification : ISO9001, CCC
    Price : negotiation
    Payment Terms : 30% T/T as advanced payment after signed contract, and 70% residual payment paid after buyer’s inspe
    Supply Ability : 8 Units/Months
    Delivery Time : 45days
    • Product Details
    • Company Profile

    Security Construction Truck Mounted Impact Attenuator 8050×2450×3900mm

    Truck mounted attenuator to ensure the special security construction works




    Main characteristic:

    The truck is equipped with special automobile anti-collision buffer vehicle buffer device and large LED display with arrow mobile security features on the automobile chassis, can be used for safety protection of highway, municipal engineering, city road, elevated road and other roads on mobile maintenance, temporary road construction and traffic accident or emergency. The purpose is to protect the construction or rescue personnel, construction equipment free from traffic accidents, to avoid a second accident, can also greatly reduce the vehicle damage.


    Main description:

    Attenuator Truck is the latest operating vehicle which independently developed by our company, it has nice exterior, compact structure, easy operation, safe and reliable features. It is a device intended to reduce the damage to structures, vehicles, and motorists resulting from a motor vehicle collision. It is designed to redirect the vehicle away from the hazard or away from roadway machinery and workers. Usually placed in front of fixed structures near highways, such as gore points, crash barrier introductions, or overpass supports.



    Attenuator Truck used ISUZU chassis, drive mode is 6 × 4, with a good view cab with air conditioning system and FM / AM radio.

    Main specification for Attenuator Truck:

    categoryItemSpecification
    VehicleProduct modelHZZ5090TFZ
    Product standardFZ09QL00
    Product nameAttenuator Truck
    Outline dimension(L×W×H)8050×2450×3900mm
    Kerb weightTotal weight(kg)9005
    Front axle(kg)3155
    Rear axle(kg)5850
    Full load weightTotal weight(kg)9200
    Front axle(kg)3350
    Rear axle(kg)5850
    Max. speed(km/h)110
    ChassisChassis modelQL1100A8MAY
    EngineModel4HK1-TC51
    Displacement(L)5.193
    Rated power/Rotate speed(kw/r.p.m)141/2600
    Max. Torque/Rotate speed (Nm/r.p.m)513/1600
    Max. Clear power (KW)140
    WheelbaseFront(mm)1680
    Rear(mm)1650
    Min. Turning circle diameter(m)≤15
    Min. Ground clearance(mm)215
    Approach angle(0)17
    Departure angle(0)10



    Crash prevent buffer device
    ManufacturerUSA Lindsay
    Model100K(2000kg-70 km/h)
    Buffer device total weight(kg)800
    Hydraulic pressure11
    Buffer device lifting speed (s/journey)10±5
    LED
    Display screen
    ManufacturerHangzhou Wuhu
    Size of display screen(L×W)(mm)1920×1600
    LED module specificationP10 LED module
    Module image resolution32×16
    Brightness(cd/㎡)≥6000
    Max. Power consumption(W/㎡)500
    Power input(V)AC220
    OutputWifi /flat computer
    Visible distance(m)≥300
    Lifting deviceManufacturerHangzhou Saiqi
    Max. Journey(mm)1800
    Max. Lifting height(mm)5000
    Max. Lifting weight(kg)250
    Hydraulic pressure(MPa)11
    Container size(mm)4720×2350×500
    Lifting light(optional)ManufacturerJiangsu Ouhui
    ModelSFW6110
    EngineBrandHonda
    Rated output electric pressure(V)220
    Rated output power(W)2000
    Light(4PC)Working pressure(V)220
    Power(W)4×500
    light quantity(lm)4×10000
    Lifting barMax. Lifting height(mm)4500
    Drive modePneumatic


    HANG ZHOU SPECIAL AUTOMOBILE REPAIR CO.,LTD
    Add: M20-15-1, Hangzhou Economic & Technological Development Area, Hangzhou , China.
    Tel: +86 571 86875791 Fax: +86 571 86721817
